In the field of mineral processing, gravity separation technology has always occupied a core position due to its low energy consumption and high cost-effectiveness. As a technical expert who has been deeply engaged in mineral processing EPCM+O services for 20 years, we will analyze the systematic solution to improve gravity separation efficiency for you through practical experience, and help mineral processing plants achieve a technological breakthrough of increasing recovery rate by 10%-25%.
1.1 Precise particle size control
A three-stage crushing system (jaw crusher + cone crusher + high-pressure roller mill) is used in the crushing stage to strictly control the ore particle size within the ideal range of 0.3-3mm
Multi-layer high-frequency vibrating screen (screen aperture error ≤ 0.05mm) is configured to ensure that more than 95% of the ore reaches the target particle size
Case data: Through particle size optimization, the jig processing capacity of an iron ore plant has increased by 40%
1.2 Efficient desludging process
The hydrocyclone group (Φ150+Φ75 combination) is used to achieve a -0.074mm fine mud removal rate of >85%
Configured with an intelligent flocculation system (PAC+PAM composite reagent), the slurry concentration can reach 35%-45%
Key indicators: After desludging, the viscosity of the slurry is reduced by 30%, and the separation efficiency is significantly improved
2.1 Jigging machine intelligent upgrade solution
Adopt servo motor drive system to achieve 0.5-5Hz stepless frequency modulation
Innovative double-peak waveform design, bed looseness increased by 25%
Add ultrasonic bed monitoring system to provide real-time feedback on mineral stratification status
2.2 Centrifugal field enhancement technology
New horizontal centrifuge (G value up to 300G) to process -0.1mm fine-grained materials
Dynamic water film control system, concentrate grade is stable at more than 95%
Energy consumption comparison: 40% lower energy consumption than traditional shaking table
Parameter dimension control range efficiency influence coefficient
Water flow rate 0.8-2.5m/sΔ1m/s=±12% recovery rate
Medium density 1.2-3.5g/cm³Δ0.1g/cm³=±8% grade
Stroke frequency 100-400 times/minuteΔ50 times=±15% processing volume
Note: Establish parameter response model through DOE experimental design to achieve multi-variable collaborative optimization
4.1 Magnetic-gravity combined process
Pre-weak magnetic separation (0.3-0.5T) removes magnetic minerals and reduces the load of the gravity separation system
Typical case: A tungsten mine uses this process, and the gravity separation recovery rate is increased from 68% to 82%
4.2 Intelligent medium system
Intelligent compensation system for resuspension density (accuracy ±0.01g/cm³)
Closed-loop circulation system with medium recovery rate>98%
Cost comparison: medium consumption is reduced by 70%
Build a three-level control system composed of PLC+SCADA+AI algorithm:
Real-time monitoring of 12 key parameters (flow, density, particle size distribution, etc.)
Adaptive adjustment system response speed <0.5 seconds
Big data analysis platform provides process optimization suggestions
Implementation case: A gold mine has increased its annual revenue by 2.3 million US dollars through digital transformation
Adopting a two-stage gravity separation + three-stage scavenging process design, the recovery rate is increased by 15-20 percentage points
Configure online particle size analyzer (Malvern Insitec series), dynamically adjust process parameters
Establish a preventive maintenance system, equipment operation rate> 95%
Through systematic technological innovation and process optimization, gravity separation efficiency can be raised to a new level. As a professional mineral processing EPCM+O service provider, we provide full life cycle services from process design, equipment selection to production optimization. Contact our technical team now to obtain customized gravity separation solutions to help you maximize mineral processing benefits.
